2022 Elling E4

location icon Massachusetts
Year 2022
Length 49 ft

Over forty years of boatbuilding experience has resulted in outstanding seaworthiness combined with exceptional levels of comfort. The interiors are spacious and light, with panoramic views from the wheelhouse. Excellent engineering, outstanding insulation and highly advanced engine mountings make these arguably the quietest semi-displacement yachts in the world. Even when cruising at eighteen knots, you will experience less noise in the deck saloon than in a luxury car travelling at a hundred kilometers an hour. All seats give outstanding support to legs and back, so you’ll be sitting comfortably even in the roughest seas.

Below decks the Elling is incomparable; enter the lower saloon and the daylight flooding in from the wheelhouse windows will make you feel you are actually on a spacious sixty-foot yacht. Comfortable ergonomic seating and the curved couch are a permanent invitation to sit back and relax. There’s even a widescreen TV which pops up and stows away at the touch of a button. The separate galley, with a full-size four-zone stove, microwave, dishwasher, washer/dryer, large fridge and separate freezer, plus two spacious Corian worktops, makes cooking a real pleasure. There’s even a wine cellar under the galley floor. It’s never been so easy to enjoy home away from home.


Year Built 2022
Category Power
Length Overall 49 ft
Beam 14 ft
Max Draft 4 ft
Cabins 3
Cabin Headroom 6'5 ft
Double Berths 1
Construction Fiberglass
Drive Type Direct
Engines 1
Total Engine Power 550 hp
Fuel Tank Cap. 400 gal
Water Tank Cap. 290 gal
Holding Tank Cap. 40 gal
Dry Weight 30000 lb
Bridge Clearance 12 ft

Engine 1 Specifications

Make: Cummins
Model: QSB6.7
Fuel: Diesel
Engine Power: 550hp
Type: Inboard
Propeller Type: 4 BladeBronze
Drive Type: Direct
Year: 2018
E4 Ultimate Package

-Flexi teak decking
-Bimini top
-Generator - 9 kW Onan
-Washer dryer
-Foldable table on aft deck
-Mesh Covers on the front windows
-Ceramic cooktop
-Rear view camera

Interior Features

-walls, doors and furniture fitted out with luxury cherry wood
-Luxury locks and hinges
-Upholstery and carpets schotch guarded
-good headroom throughout

Helm Saloon comprising of
-Helm seat in leather, mechanically sprung and fully adjustable
-Three windscreen wipers with adjustable intervall switch
-Luxury wooden steering wheel
-Engine instrument panel
-single lever engine control
-extensive switch panel with circuit breakers
-curved settee and table
-LED lighting with dimmer
-Chart tray
-book case
-loudspeakers for radio
-Instrumentation, comprising of:
- Led control panel
- Rudder position indicator
- water level indicator
- fuel level indicator
- alarms
-Tri data instruments
-Navigation equipment as ordered

Lower saloon comprising of
-LED lighting with dimmer
-indirect lighting
-two table lamps (Freivokh design)
-cupboards all around
-curved settee and large table with nice decoration
-two luxury comfortable chairs
-Wide screen television in cherry furniture
-carpet on floor to choice of customer
-overhead loudspeakers for Radio

Front Cabin
-Lay out as ordered. (two single beds or double bed + settee)
-LED overhead lighting
-bed reading lights
-indirect lighting
-large wardrobe

Owners cabin
LED overhead lighting
bed reading lights
indirect lighting
Queen size bed with access on both sides
one hanging cupboard
two cupboards with shelves
two small cupboards
Large mirror
Entrance to second bathroom and storage

Side cabin
lay out as ordered
Overhead LED lighting
bed reading lights (only if bed is appliccable)
acces hatch to engine room (alternator side)
Safe (under floor)

2 Heads Comprising of:
Overhead LED lighting
LED lighting on worktop
Separate shower cubical
Luxury showerdoor in safety glass
Electrically operated head (full size)
Bathroom accessoiries
Heated towel rack (if central heating is ordered)
Laminate flooring in teak motive
Thermostatic shower control
Extraction fan
corian worktop

Galley Comprising of :
two large Corian worktops on both sides of galley
double sink
four ring cooker
full size hob extractor
oven microwave
full size fridge freezer
wine cellar
scratch free laminate flooring with teak motive
several cupboards on both sides of galley

Deck Specifications

-CE Ocean classification A
-Hull colour: White
-Deck, white
-Integrated deck water drains
-Integrated steps in Hull, Port & Starboard
-Transom Access by rear steps with comfortable enlarged teak steps
-Aft deck seating
-second seat on aft deck, integrated in railing with storage inside
-Diving platform
-Teak decking on diving platform
-Stainless steel access ladder
-wide Stainless steel heavy duty fender strip
-800 mm high stainless steel handrails
-stainless steel hinged aft gate
-6 stainless steel deck cleats
-Stainless steel flag poles
-Non skid deck surface
-Integrated forward sundeck
-Integrated forward seating
-Spray dodger around rear deck
-Integrated deck storeage for 6 person life raft (and / or) mooring lines
-integrated deck storeage for cleaning stuff (like buckets, waste bin etc)
-electric operated mast installation
-hot & cold transom shower
-tool set and first aid kit
-mooring lines and 4 fenders
-vacuum cleaner

Technical Specifications

-Bowthruster (95 kgf)
-Electric anchor winch, operated from two positions
-Anchor fitted with 30 meters of chain
-Navigation lights
-Rear deck lights
-Side lights
-Cathodic protection by zinc annodes
-Black water tank
-Electric operated trim interceptors

Comfort and Safety

-Double glazing in deck saloon with insulated window frames
-Tinted safety glass
-Venetian blinds in decksaloon
-2 off escape hatches
-10 portholes with screens
-front opening window
-rear opening window
-large electric operated power slideroof with pneumatic seal.
-automatic fire extinguisher in engine room
-two manual fire extinguishers
-fire alarm in engine room
-fire alarm in living area
-2 automatic bilge pumps
-manual bilge pump
-Water alarm
-Engine bed integrally moulded with hull for maximum strength
and vibration absorption
-excellent engine room insulation, existing of 7 differing material layers:

Available Engines
  • 435 hp 6 cylinder Volvo Penta D6 common rail Diesel  engine (including Aquadrive for extreme low  noise and vibration level) Speed Max. 17 kts
  • 550 hp 6 cylinder Cummins QSB 6.7 common rail Diesel engine (including Aquadrive for extreme low  noise and vibration level) Speed Max. 20 kts
  • 600 hp 6 cylinder Cummins QSB 8.3 common rail Diesel engine (including Aquadrive for extreme low  noise and vibration level) Speed Max. 21 kts
  • Other engines may be considered, depending on dimensions and system requirements.
Engine and Steering Specifications

-Stainless steel Drive shaft with water injected bearings
-Dripless "Tides-Marine" shaft seal for dry bilge.
-4 blade propellor
-water cooled dual chamber exhaust silencer
-Hydraulic steering system
-high efficiency rudder

Electric Systems

-Invertor 110 V 2500 W
-Battery charger 80 A, 24 V
-Shore support with socket and 50 foot cable
-24V board system
-Automatic switch over from shore power to invertor operation or
 generator operation
-Separate service batteries and engine bateries
-4 x 200 Ah service gel batteries (maintenance free)
-2 x 85 Ah dry light weight start batteries (maintenance free)
-Ability to switch electrical system from engine to service batteries
-several 110 V power points throughout boat
-Automatic circuit breakers on all 24V and 110 V Circuits up to 50 A
-Melt circuit breakers on all other (over 50 Amp) circuits
-Central main switch
